Hydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 Ton



Features

1.The frame is heavy-duty as well as compact and it assures precise results.It is made of high quality mild steel and it has undergone systematicmechanical processes.

2. Electric welding of high precision

3. Usage of high-tech boring machines for extreme precision parts

4. The composite series has been designed for applications in which structural rigidity and lexibility in terms of production are the particular rerogatives required. Machines with several actions from the top or bottom or pecial solutions enable complex shapes and large dimensions to be achieved in a number of different industries.

5. It is convenient to clean and change oil.

6. Factory full set of solution

Parameters

Mold         unit63T100T160T200T250T315T500T630T800T1000T1250T1500T2000T3000T
Main cylinder (slider) process specs Max.press forceKN630100016002000250031505000630080001000012500150002000030000
Max.return forceKN15010031545054063010001000120016002100250030004000
Down speedmm/s100100160160140140140250200150150140150150
Slow speedmm/s2015151512151515151512151212
The proportion of floating pressing speedmm/s20.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.00
Press speedmm/s101010107888886866
Return speedmm/s12012012011095100100150150120120120120120
Max.strokemm400500500500500500600600600600600600600600
Top cylinder process specsMax.ejection forceKN2804404509009001250180022002200275027503150800010000
Max.pull forceKN2803604507507501250180022002200275027503150800010000
Max.strokemm150150150150150150150150150150150150150150
Eject speedmm/s80346555505050606060 60606060
Floating speedmm/s20.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.0015.00
Return speedmm/s8042957070505060606060606060
Upper center cylinder process specsMax.press forceKN606060125150125200200240240300400400500
Max.return forceKN303030767676130130140140200260260300
Max.strokemm3030304545455050505050505050
Under center cylinder process specsMax.press forceKN70701251601602002003003003004005008001000
Max.return forceKN404075100100100100200200200260315500600
Max.strokemm150150150150150150150150150150150150150150
Upper floating cylinder processMax.press force KN1201201302502503004004004804805005008001000
Max.return forceKN606065150150160200200240240250250520600
Max.strokemm4545506060707070707070707070
Effective worktable sizeL-Rmm58072078010001000100012001320140016001760180020002400
F-Bmm49058064094094096011401200120013501460150016001800
Max.pressure of liquidmpa2525252525252525252525252525
Max.filling heightmm120120120120120120120120120120120120120120
Main motor powerKW7.511.518.5222230486782100100127220300
Hydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 TonHydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 Ton
Hydraulic Press Machine Oil Press High Performance Frying Pan Fry Pan 200 Ton

AFTER-SALE



1.Personnel training
Free training for about one week.

2. After-sale service
One year warranty.During warranty period,free maintenance service can be provided.(except man-made faults or damages arising from irresistible natural factors)

3.Installation
Customers need to pay the commission to our proffessional engineer, and travel expense is on foreign customer.(Including round ticket and accommodation cost)

Our company is an ISO 9001 certified Company, and as an approved supplier for the automotive sector, has also received the CE certificates .
